Infrared heating for a concert hall with wall-mounted heaters

Nine Teplov P3000 heaters were installed to heat the concert hall at a cultural centre in Haivoron. The distinctive feature of this project is the installation of the heaters on the walls, angled towards the area to be heated. With a ceiling height of 8 metres, the equipment was mounted 6 metres above the floor.

This approach requires heater output and placement to be selected together. In a hall with audience seating, heat needs to be directed towards the occupied space, with controls that allow for different occupancy levels.

The task — heating a high-ceilinged hall of 300 m²

A concert hall is used differently from a continuously occupied room. Between events, a lower temperature can be maintained, while the hall needs to be warmed up before the audience arrives. When only some seats are occupied, selected areas may need heating.

This project provided for two temperature settings and the option to switch the heaters on in groups.

ParameterProject solution
Facility Concert hall with a stage at a cultural centre
Location Haivoron
Floor area 300 m²
Ceiling height 8 m
Equipment 9 × Teplov P3000
Total rated power 27 kW
Installation On the walls at an angle, 6 m above the floor
Temperature settings +10 °C between events; warming up to +18 °C before events
Control Switching individual groups of heaters

Installing ceiling heaters on walls — how the solution works

Ceiling infrared heaters can also be installed on walls when the manufacturer permits this arrangement for the selected model. Adjustable wall brackets are available for the P3000, allowing the heater’s tilt to be set.

Infrared radiation transfers heat to people, objects and surfaces within the heater’s coverage area. Warmed surfaces then exchange heat with the air. When installed on a wall, the heater is directed towards the required part of the room, taking account of the distance and radiation pattern.

In Haivoron, the heaters were mounted above the audience seating, keeping the floor and aisles clear. Angling the units directed radiation from the walls into the hall.

Teplov P3000 heaters mounted on the walls of a concert hall in Haivoron Teplov heaters installed at an angle on the walls of a cultural centre hall

Why performance depends on placement calculations

The view that a ceiling heater necessarily becomes less effective when mounted on a wall overlooks the details of the installation. The mounting method alone does not determine heating performance: the direction of heat flow, distances and adequate output all matter.

For wall installations, Teplov specialists calculate the room’s heat loss and determine heater positions. They consider installation height, tilt angle, radiation distribution and coverage of the required areas. The aim is to avoid pronounced unevenness, where nearby seats receive too much radiant heat and more distant ones receive too little.

The 6-metre installation height and layout used in this hall are therefore not a universal solution. Another room requires its own calculations and a check of the permitted installation clearances.

Controlling heating according to hall occupancy

The installation allows heaters to be switched on in groups. When the hall is partly occupied, units serving the required section can operate without all the equipment having to be switched on.

A temperature of around +10 °C is maintained between events, with provision to warm the hall to +18 °C before events. These settings allow heating to follow the way the space is used.

The installed 27 kW represents the system’s rated power. Electricity use depends on how many heaters are switched on and how long they operate, so this figure should not be treated as continuous consumption.

What this project demonstrates

The Haivoron project demonstrates the use of Teplov P3000 heaters installed at an angle on walls. The solution combines heating for a high-ceilinged concert hall, clear aisles and the ability to control separate groups of units.

Another heating arrangement is shown in the project for heating a cultural centre’s auditorium and stage. General system selection guidance is available in the section on heating public and commercial premises.

Need to heat a hall with heaters installed on the walls?Contact Teplov for a heating calculation. Send the room dimensions, insulation details, a seating plan and photographs of the walls and ceiling. Include your desired temperature and event schedule to help determine the output, heater placement and control arrangement.

Questions about installing heaters on hall walls

Can a ceiling infrared heater be installed on a wall?

Yes, if the manufacturer permits this installation method for the specific model. Adjustable wall brackets are available for the Teplov P3000. Height, tilt and distances from surrounding structures are selected according to the equipment requirements and conditions in the room.

Will wall installation make the heating less effective?

Not necessarily. Changing a heater’s position affects heat distribution, so the result depends on calculations and the direction of radiation. Wall installation should not automatically be considered either equivalent to ceiling installation in all conditions or inherently less effective.

At what angle should a heater be installed?

There is no universal angle for every hall. The angle is selected according to installation height, distance to the area being heated, the position of people and the heater’s radiation characteristics. It must provide the required coverage while meeting installation requirements.

Can only the occupied part of a concert hall be heated?

Separate group control can be provided, as in this project. It allows the equipment to focus on the areas in use. The building’s overall temperature conditions must also be considered: an open hall does not become a set of spaces with fully independent temperatures.
