Heating a creative arts centre in the village of Kharaluh

Four Teplov B1350 infrared heaters were installed to heat a room at the creative arts centre in the village of Kharaluh. The heaters were mounted beneath the ceiling, leaving the floor clear for activities, furniture and children moving around.

This project illustrates ceiling heating in a space used for creative activities. For facilities like this, heater placement and adequate output matter, as does the option to coordinate heating with the class timetable.

The task — heating the room while keeping space free

Activity rooms need usable space for learning materials, equipment and group work. Floor-standing heaters take up some of that space and sit in areas where people move around.

Ceiling infrared heaters allow equipment to be positioned away from the main activity area. When installation height and clearance requirements are met, this arrangement also reduces the likelihood of children accidentally touching the heaters’ hot surfaces.

The solution — four Teplov B1350 heaters

The photographs show one room fitted with four heaters.

ParameterProject details
Facility A room at a creative arts centre
Location Kharaluh village, Rivne region, Ukraine
Equipment Teplov B1350
Quantity 4 heaters in one room
Placement Beneath the ceiling

Infrared radiation transfers heat to surfaces and objects within the heaters’ coverage area. The warmed surfaces then transfer some of that heat to the air. System selection therefore takes account of where activities take place, the installation height and the room’s heat loss.

The practical result of ceiling installation in this project is heating equipment that takes up no floor space.

Room at the creative arts centre in Kharaluh with Teplov B1350 ceiling heaters Teplov B1350 heaters installed beneath the ceiling of an activity room Teplov infrared heaters inside the creative arts centre

Flexible heating for rooms with different timetables

Teplov allows a modular system to be built from individual heaters. With a suitable wiring and control arrangement, individual units or groups can be switched on and off independently. The need for this type of control is discussed at the design stage.

For a facility with several rooms, separate temperature control can be provided in each one. This allows heating to follow different activity timetables: maintaining the occupied temperature where classes are taking place and a lower temperature in rooms that are unused for longer periods.

Grouping heaters and regulating temperature serve different purposes. The first determines which equipment operates; the second maintains the required temperature setting.

Night setback — lowering the temperature without shutting heating down

Once classes have finished, it is not always necessary to maintain the daytime temperature until the following morning. If the system is equipped with programmable controls, it can automatically switch to a lower temperature setting.

The heating remains under thermostat control. As the room cools, the heaters switch on to maintain the set temperature. The lower setting is selected to prevent freezing and preserve the conditions required for the building’s operation.

Savings come from reduced heat loss: with other conditions unchanged, a smaller temperature difference between indoors and outdoors means the room loses less heat. This can reduce electricity use compared with maintaining the daytime temperature around the clock. The amount saved depends on insulation, weather and the duration of the setback period.

The return to the occupied temperature is scheduled in advance, allowing time for the room to warm up before classes begin.

Selecting heating for a creative arts centre or studio

Another example of equipment used in a public facility is the cultural centre heating project in Liubotyn. General selection principles are covered in our section on heating commercial and public premises.

Planning heating for an activity room?Contact Teplov with the floor area, ceiling height, insulation details and operating timetable. This information will help determine the equipment, installation positions and suitable controls.

Questions about heating activity rooms

Can only some of the heaters be switched on?

Yes, if the wiring and control arrangement allows individual heaters or groups to operate independently. This is agreed at the design stage. The number of heaters in operation must match the room’s current heating requirements.

How can the temperature be lowered automatically after classes?

Programmable controls can be used to set periods with occupied and reduced temperatures. One example is our store heating project with programmable controls.

Should the heating be switched off completely at night?

To maintain a minimum temperature, the system can remain enabled at a lower setting. The thermostat will switch the heaters on as needed. The setting is chosen according to the building’s condition, its services and the time needed to warm the room up again.

Are four B1350 heaters enough for my room?

Four heaters are the configuration used for this particular room, not a universal solution. For another space, heat loss, ceiling height, ventilation, glazing and the required temperature must be considered.
